SPA-600DSP

High Effificiency 2-Channel Class-D Amplififier Module for Professional Applications
The SPA-600DSP is an amplififier module featuring  2 output channels specififically designed for two-way  loudspeakers system. The highly compact design,  integrating 2 channels and the power supply in a  single chassis, makes the SPA-600DSP a unique  product, capable of delivering up to 800W on a  single 8 Ohm channel, granting the highest power  available for driving speakers.
  The SPA-600DSP is fully compatibile with all  existing LIHUI DSP solutions.

Specififications
General
Maximum output power per channel @ 4 Ω          450watt
Maximum output power per channel @ 8 Ω          300watt
Maximum output power per channel @ 16 Ω        150watt
Maximum output power @ 8 Ω Bridged                  800watt
Maximum output power @ 16 Ω Bridged                400watt

Audio
Frequency response : 20 Hz - 20 kHz ( +0/-1 dB) @ 1 W, 8 ohm
S/N ratio : 100 dB (A weighted)
Crosstalk separation : -65 dB @ 1 kHz (4 ohm)
Input sensitivity @ 8Ω : 0.775 V / +0 dBu
Max input level: 2.7 V / +10.8 dBu @ 32 dB gain
Input impedance : 10 k ohm balanced
THD+N : < 1% from 0.1 W to full power (typically < 0.05%
Damping factor > 200 @ 100 Hz
AC Mains Power:
Power supply: 115V/230V 50-60HZ
Construction
Dimensions (L x W x H) : 280 mm x 148 mm x 83 mm
Weight : 2KG
